SPOT LIGHT

The output options become visible when a POINT-LIGHT is selected.

Select the variables you want to output and click on the Print Light Hotspots button.

pca spotlight values

Output Options​

  • comment object-name and type
  • hotspot to output as krpano hotspot xml
  • name the object name
  • basic-settings can be defined in the add-on preferences
  • style user input
  • mode light mode (SUN, POINT, SPOT)
  • location ath/atv
  • distance
  • target
  • angle
  • penumbra
  • intensity
  • color
  • castshadow

Output Examples​

<!-- Name=Spot | Type=LIGHT -->
name="Spot"
type="threejslight" keep="true"
style="spotlight"
mode="spot"
tx="-961.98" ty="-0.0" tz="274.09"
targetx="-961.98" targety="1414.21" targetz="1688.3"
angle="45.0"
penumbra="0.15"
distance="2000.0"
intensity="20.0"
color="0x47FFF8"
castshadow="true"

If the hotspot checkbox is activated, the output is formatted as krpano-hotspot xml:

<!-- Name=Spot | Type=LIGHT -->
<hotspot name="Spot"
    style="spotlight"
    tx="-961.98" ty="-0.0" tz="274.09"
    targetx="-961.98" targety="1414.21" targetz="1688.3"
    angle="45.0"
    distance="2000.0"
/>
